- General Information
- Manufacturer
- Zhejiang Dahua Technology Co., Ltd.
- Manufacturer Website Address
- http://www.dahuasecurity.com
- Brand Name
- Dahua
- Product Type
- Video Door Phone
- Technical Information
- Wiring Type
- 2-wire
- Ingress Protection (IP) Rating
- IP65
- Impact Protection (IK) Rating
- IK07
- Display & Graphics
- Screen Size
- 17.8 cm (7")
- Display Screen Type
- TFT
- Screen Resolution
- 1024 x 600
- Camera
- Image Sensor Type
- CMOS
- Camera Resolution
- 2 Megapixel
- Horizontal Viewing Angle
- 160°
- Vertical Viewing Angle
- 87°
- Diagonal Viewing Angle
- 177°
- Power Description
- Input Voltage
- 48 V DC
- Physical Characteristics
- Product Color
- Silver
- White
- Product Material
- Anodized Aluminium
- Polycarbonate
- ABS
- Miscellaneous
- Application/Usage
- Villa
- Door Entry
- Additional Information
- DHI-VTO2202F-P-S2:
- Dimensions 130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12")
- Power Consumption: ≤ 12W
- Net Weight: 0.35 kg (0.77 lb)
- Gross Weight: 0.4 kg (0.88 lb)
- Video intercom function
- Access control function that supports for two locks
- Use the app to talk to visitors or unlock the door remotely on your phone
- Compatible with 2-wire and RJ45 interfaces
- Supports H.265 incoding
- Support surface and flush mount
- PoE
DHI-VTH5422HW:
- 2.5D screen glass
- 6-channel alarm input and 1-channel alarm output
- Supports standard PoE or power over 2-wire switch
- H.265 video coding (H.264 by default)
- Supports daisy chain topology
- Dimensions 189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06")
- Power Consumption: Standby ≤ 2W, working ≤ 6W
- Net Weight: 0.388 kg (0.86 lb)
- Gross Weight: 0.74 kg (1.63 lb)
- Supports connecting through RJ45 port
- Supports guide rail mount
